LED Fused Terminal Blocks Connectors Strips and Fuse Holders
- Type:
- Test disconnect terminal block, with two test sockets for 4 mm test plugs, or for receiving bridge bars or screw bridges
- Nominal Voltage:
- 400 V
- Nominal Current:
- 41 A
- Connection Method:
- Screw connection
- Rated Cross Section:
- 6 mm²
- Cross Section:
- 0.5 mm² - 10 mm²
- Color:
- gray
Industrial control cabinets require robust overcurrent protection alongside swift fault isolation. When a fuse blows in switchgear, an integrated fused terminal block with led provides an immediate visual fault alert. Pairing these assemblies with Disconnect & Test Terminal Blocks enables seamless diagnostic testing on secondary instrumentation loops without interrupting system power.
Rapid Troubleshooting and Reliable Circuit Isolation
Control cabinets utilize a modular fused connector block to shield signal paths from current spikes. High-vibration environments demand stable clamping and touch-safe housings that prevent accidental contact. ZGHD Electric manufactures these assemblies with flame-retardant PA66 polyamide to maintain high dielectric strength.
Practical Field Operations
-
Visual Status Indication: A dedicated terminal fuse holder illuminates immediately when fuses blow, slashing system downtime.
-
Safe Signal Separation: Circuits isolate smoothly through sliding disconnect contacts to verify signal integrity without lifting field wiring.
Deploying a multi-position fused terminal strip across distribution rails simplifies wire routing. For measurement and protective circuits, ZGHD Electric manufactures the JHD5-6S Test Disconnect Terminal Block, featuring dual 4 mm test sockets for rapid probe insertion.
Implementation Steps
-
Verify Voltage Ratings: Match nominal current capacity with prospective branch loads.
-
Standardize DIN Rails: Ensure compatibility with NS 35 rail mounting profiles across all enclosures.
Specifications: ZGHD Electric JHD5-6S
| Parameter | Value |
|---|---|
| Model | JHD5-6S |
| Rated Voltage | 400 V |
| Rated Current | 41 A |
| Wire Range | 0.5 mm² – 10 mm² |
| Connection Type | Screw clamp |
| Housing Material | PA66 (UL 94 V-0) |
| Mounting Standard | NS 35 DIN Rail |
| Model | Function | Wire IEC cross-section | Wire UL | Thickness |
| JHD5-6S |  |
4 mm² 6 mm² 4 mm² |
10 AWG 12 AWG 10 AWG |
8.2 mm |
| Maximum current | Number of packages | Thickness/Height( )/Width mm |
Rated voltage/rated current/rated cross-sectior |
| 57A | 45 | 8.2/51.5/72 | 400 V/57 A/6 mm² |
Specfication:
| End cover | D6S |
| Cross-connection 10-Polo,Separable | ZL2-6S ZL3-6S ZL10-6S |
| Small Partition | CP6S |
| Marking tags | ZB8 |
| Screw/Tightening torque(Nm) | M4/1.2 |
| Material | PA |
| Flame retardant rating UL-94 | V0 |
| Dimensions |  |
With universal mounting feet for standard top-hat(Ω profile) and G-profile DIN rail mounting.
